Audiovox CNP-1000C User Manual

Quick start guide, Cnp-i000c, Welcome

background image

Welcome

to the world of XM

®

or, as we like to call it,

“The XM Nation”! With your decision to subscribe to XM

Satellite Radio, you have joined a revolution that is sure to

change radio forever. We are thrilled you have chosen XM

to be your satellite radio service provider. We will do every-

thing we can to make your listening experience second to

none!

The XM Connect and Play is a fully integrated XM receiver

and the only thing you need to receive XM Satellite Radio

through your XM Ready

®

home or portable audio system.

Getting XM couldn’t be simpler*.

The following instructions will guide you through the basics

of setup, signal acquisition, and XM service activation. For

detailed instructions on using XM with your XM Ready

system—such as how to select channels and navigate the

XM channel lineup—refer to the user manual that came

with your XM Ready home or portable audio system.

*Hardware and required basic monthly subscription sold separately. Premium channel available at additional monthly cost. Other fees
and taxes, including a one-time activation fee may apply. Subscription fee is consumer only. Reception of the XM signal may vary
depending on location. All fees and programming subject to change. Subscriptions subject to Customer Agreement available at
xmradio.com. Only available in the 48 contiguous United States. ©2005 XM Satellite Radio Inc. The XM name, XM Ready, Connect and
Play, and related logos are trademarks of XM Satellite Radio Inc. All rights reserved. All other trademarks are the property of their
respective owners

Caution: The XM Connect and Play is for use only with XM Ready home and portable audio systems. It will not
work with any product that does not say “XM Ready” or that is for automotive use. Use your XM Connect and

Play only with approved XM Ready audio systems and accessories. Do not modify wires or other components in any way.
Doing so could: a) cause harm to you or others; b) damage your XM Connect and Play and/or XM Ready audio system or;
c) void your product warranty.

The XM Satellite Radio service is broadcast to you from

satellites in orbit over 20,000 miles above the earth’s

surface. XM also has installed a network of terrestrial

repeaters across the country to enhance satellite signal

strength.

Although the XM Connect and Play can be mounted

outdoors, it is usually not necessary. Most users simply

place their antenna in the windowsill of a south-facing

window with no obvious obstructions to the sky. Try various

locations for your XM Connect and Play as you may be

surprised at the range of options you have.

Before You Get Started

The XM Connect and Play, an innovative digital antenna

platform developed by XM, uses the latest XM technology

to allow consumer electronics manufacturers a standard by

which to make their products XM Ready. It is something

that only XM can offer. The XM Connect and Play is a fully

integrated XM receiver and can be used with any XM Ready

home or portable audio system.

Note: This product will not work with automotive audio systems,

which may be labeled XM Ready. For specific details on supporting

products and accessories that work with XM Ready automotive

systems, visit: http://www.xmradio.ca

What is the XM Connect and Play?

An audio system labeled “XM Ready” means that the

system with the addition of an XM Connect and Play has

everything you need to play XM. Everything else is built

right in.

What is XM Ready?

About XM Satellite Radio:

XM Satellite Radio is North America’s leading provider of

satellite radio with more than 6 million subscribers. XM

offers up to 100 digital radio channels: commercial-free

music channels ranging from hip hop to opera, rock to

bluegrass, big band to reggae; talk radio channels, including

news, sports, comedy, and children’s programming.

Subscribers pay a low monthly fee for the XM service,

which was named Best Radio Service by the music

industry’s leading magazine Billboard at the 2004 Digital

Entertainment Awards.

Exclusive programming on XM includes Major League

Baseball

®

games for every team, all season long. You can

listen to XM on a variety of satellite radio receivers for the

vehicle, home, and portable use.

For more information about XM, visit http://www.xmradio.ca

Quick Start Guide

CNP-I000C

AUDIOVOX ELECTRONICS CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof,

under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be

repaired or replaced with new or reconditioned product (at the Company’s option) without charge for parts and repair labor.

To obtain repair or replacement within the terms of this Warranty, the product is to be delivered with proof of warranty coverage (e.g., dated bill of sale),

specification of defect(s), transportation prepaid, to an approved warranty station or the Company at the address shown below. This Warranty does not extend

to the elimination of externally generated static or noise, to costs incurred for installation, removal, or reinstallation of the product, damage to speakers,

accessories, or vehicle and home electrical systems, or malfunction of satellite transmissions, repeater signal, or receiver unit.

This Warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered or been damaged through alteration, improper

installation, mishandling, misuse, neglect, accident, or by removal or defacement of the factory serial number/bar code label(s). THE EXTENT OF THE

COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE

COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.

This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT-

ABILITY, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY HEREUNDER INCLUD-

ING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 48 MONTHS FROM DATE OF ORIGINAL PURCHASE.

IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER

WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. No person or representative is authorized to assume for the Company any liability other than expressed

herein in connection with the sale of this product.

Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage so the above

limitations or exclusions may not apply to you. This Warranty gives you specific legal rights and you may also have other rights which vary from state to state.

U.S.A.: AUDIOVOX ELECTRONICS CORPORATION, 150 MARCUS BLVD., HAUPPAUGE, NEW YORK 11788, 1-800-645-4994

CANADA: CALL 1-800-645-4994 FOR LOCATION OF WARRANTY STATION SERVING YOUR AREA.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference,

and 2. This device must accept any interference received, including interference that may cause undesired operation.

IMPORTANT: THE FCC AND FAA HAVE NOT CERTIFIED THE XM CONNECT AND PLAY FOR USE IN ANY AIRCRAFT (NEITHER PORTABLE NOR PERMA-

NENT INSTALLATION). THEREFORE, XM CANNOT SUPPORT THIS TYPE OF APPLICATION OR INSTALLATION.

Upon activation, you should be up and running. Your XM

Ready audio system’s user manual will provide the specif-

ics on finding your way around the award-winning world of

XM and its up to 100 digital channels of audio entertain-

ment. Now, sit back and experience radio as it was meant

to be!

Using XM Satellite Radio

For customer service, visit our XM Listener Care Center

online at https://activate.xmradio.ca/care/en/. There, you

can activate and deactivate radios, manage your account,

add premium services, make inquiries, and more.

Or, contact the XM Listener Care Center by calling 1-877-

GET-XMSR (1-877-438-9677), Monday through Saturday,

6:30 am – 12:00 am and Sunday, 8 am – 8 pm EST.

Contact XM Listener Care

Step 1: Setting Up Your XM Ready System

Step 3: Activating Your Service

Step 2: Acquiring XM Signal

To activate via the Internet: Visit

https://activate.xmradio.ca/

To activate via phone: Call 1-877-GET-XMSR (1-877-438-9677).

A one-time activation fee will apply.

Printed on Recycled Paper

© 2005 Audiovox Corporation. All rights reserved.

Warranty

Technical Information

Height: 29.2 mm (1.15 inches), Width: 77.0 mm (3.03 inches), Depth: 91.3 mm (3.60 inches), Weight: 10 oz (310 g), Power: 2.2 W

FCC Information

The XM Connect and Play is the only component you need

to get XM through your XM Ready audio system. With

power to your XM Ready audio system turned OFF, simply

connect the end of the antenna cable to the port on the

back panel of your XM Ready audio system labeled “XM.”

A one-time activation fee is required to establish an account and

activate service with XM Satellite Radio. Applicable activation

charges will be added to your first bill.

Turn on the power to your XM Ready audio system. Choose

XM as the input source per instructions in your XM Ready

audio system’s user manual. Tune to Channel 1, the XM

Preview Channel.

Move your antenna to various window locations around

your home to see where the best reception will be

received. Most XM customers place the antenna in a

south-facing window with a clear view to the sky. There are

two ways to confirm that you have strong signal reception:

Note: The optional CNP-HEXT Connect and Play extension cable
is available for installations requiring additional cable length.

Note: Carefully check your XM Satellite Radio ID.
The letters I, O, S, and F are not used.

Once you can hear the Channel 1 broadcast clearly and consistently,

you are ready to activate your service

1. Signal strength meter: Some XM Ready systems display

a signal strength meter for determining signal strength.

Refer to your XM Ready audio system’s user manual for

more information. Otherwise, use the Preview Channel

to determine if you are receiving the signal.

2. Hear XM Preview Channel: If you are tuned to Channel 1

and hear the audio, you are receiving satisfactory signal

strength to receive the XM service. If you do not hear

any audio, it means your antenna is not receiving an

adequate satellite or terrestrial repeater signal and must

be moved to a more appropriate location.

1. Before activating XM service, make sure your XM equip-

ment is tuned to the XM Preview Channel (Channel 1).

2. Determine your eight-character XM Satellite Radio ID

number by referencing the label on your XM Connect and

Play packaging, rear cover, or by selecting channel 0. The

ID number will appear on the display. Write the number

here:

3. Activate your XM Satellite Radio service. Make sure you

have a major credit card and your XM Satellite Radio ID

number handy.

Getting Started: 3 Easy Steps!
