Konica Minolta KIP Color 80 - Manual (Page 8)

2
1. 2 Specifications
Configuration Console
Acceptable media width
914mm (36”) maximum
Stacking Capacity 200 sheets of plain paper
Wait time 0.5 second
Input power Voltage: 100-240VAC
Current: 0.5A (at 100V)
Frequency: 50/60Hz
Power consumption 50W maximum
Environmental conditions 10-32.5 degrees centigrade, 20-85%RH (Non condensing)
Acoustic noise 57 db or less (during operation with an integrated printer)
Maschinenlärminformations-Verordnung 3. GPSGV:
Der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger
gemäß EN ISO 7779
Outer dimension 1,069mm (Width) x 865.6mm (Depth) x 1,312mm (Height)
(1,436mm in depth for using ST Wire Tray)
Weight Approximately 46.8kg (103.2 lbs)
NOTE
Auto Stacker (K-113) accepts the inlet voltages of 100 to
240VAC without additional voltage transformation.
NOTE
Auto Stacker (K-113) is intended for the exclusive use of the KIP Color 80 Digital Color
Printer (K-107).
NOTE
These specifications are subject to change without notice.
