Configure Load Balancer Redundancy on Allied Telesis Routers and Switches 8
Either:
disable gui
disable http server
Or:
set http server port=8080
enable vrrp
create vrrp=2 over=vlan3 ipaddress=192.168.1.202
enable lb
add lb respool=web selectmethod=roundrobin faillast=no
add lb resource=web1 ip=192.168.1.1 port=80 respool=web
add lb resource=web2 ip=192.168.1.2 port=80 respool=web
add lb virtualbalancer=web publicip=172.214.1.2 publicport=80
respool=web
enable lb virtualbalancer=web
set lb redundancy peerip=192.168.2.2 listenport=5000
redunip=172.214.1.2 publicint=vlan2 redunmask=255.255.255.0
enable lb redundancy
enable trigger
create trigger=2 module=loadbalancer event=master
script=master.scp
create trigger=3 module=loadbalancer event=slave script=slave.scp
create config=lb_redun.cfg
set config=lb_redun.cfg
6. Disable the GUI and the HTTP server on port 80
7. Configure VRRP
8. Configure load balancing
9. Configure triggers
10. Save the configuration
