Atlantis Land A02-IPCAM5 - Manual (Page 10)

7
2.2 Client Setting
Mode: Click the pulldown box to choose between MPEG4 and MJPEG video compression
mode.
Note：MJPEG streaming is unavailable if RTSP mode is ON.
View Size: Select the desired display image resolution to 640X480 or 320X240.
Protocol: Select the transferring protocol from TCP, UDP, HTTP and Multicast.
Video Buffer: Turn the Video Buffer function On/Off. The Video Buffer function makes the
streaming more smoothly in unsteady network environment, but might cause a little delay
in live viewing.
2.3 Image Setup
You can use the tool bar to optimize video brightness, contrast, and
saturation.
2.4 Live View
Snapshot:
You can capture a still image shot by the camera and save it in your computer.
1. Press , and a snapshot window will appear.
2. Click “Save” to save the picture in your computer.
3. Click “Close” to return to the view page.
Zoom in / out the image via the monitor window
