40
-EN
• The XM or SIRIUS antenna is not connected to the XM or
SIRIUS radio module.
- Check whether the XM or SIRIUS antenna cable is attached
securely to the XM or SIRIUS radio module.
• Radio is being updated with latest encryption code.
- Wait until encryption code is being updated. Channels 0 and 1
should function normally.
• XM or SIRIUS signal is too weak at the current location.
- Wait until the car reaches a location with a stronger signal.
• Radio is acquiring audio or program information.
- Wait until the radio has received the information.
• The channel currently selected has stopped broadcasting.
- Select another channel.
• The user has selected a channel number that does not exist or is
not subscribed to.
- The unit will revert back to the previously selected channel.
• There is no artist name/feature, song/program title, or additional
information associated with the channel at that time.
- No action needed.
• If an error or other problem occurs.
- Change channels or consult your Alpine dealer.
Specifications
FM TUNER SECTION
AM TUNER SECTION
USB SECTION
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
DETACHABLE FRONT PANEL SIZE
• Due to continuous product improvement, specifications and design
are subject to change without notice.
Indication for SAT Receiver Mode
(SIRIUS mode)
(XM mode)
(SIRIUS mode)
(XM mode)
Tuning Range 87.7-107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 530-1710 kHz
Sensitivity (IEC Standard) 22.5 µV/27 dB
USB requirements USB 1.1/2.0
Max. Power Consumption 500mA
File System FAT12/16/32
MP3 Decoding MPEG-1/2 AUDIO Layer-3
WMA Decoding Windows Media™ Audio
(WMDRM10 is supported)
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response* 5-20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
* Frequency response may differ depending on the encoder
software/bit rate.
Power Requirement 14.4 V DC
(11-16 V allowable)
Power Output 18 W RMS × 4*
*Primary amplifier ratings per CEA-2006 Standard
• Power output: measured at 4 Ohms and 1% THD+N
• S/N: 80 dBA (reference: 1 W into 4 Ohms)
Maximum Pre-Output Voltage 2 V/10 k ohms
Weight 1.0 kg (2 lbs. 3 oz)
Width 178 mm (7")
Height 50 mm (2")
Depth 156 mm (6-1/8")
Width 170 mm (6-3/4")
Height 46 mm (1-13/16")
Depth 28 mm (1-1/8")
Width 108 mm (4-1/4")
Height 46 mm (1-13/16")
Depth 36 mm (1-7/16")
