Key combination Description
Fn+F9 Start or pause playback of Windows Media Player.
Fn+F10 Stop playback of Windows Media Player.
Fn+F11 Skip to the previous track.
Fn+F12 Skip to the next track.
Fn+Insert (B570e)
Fn+PgUp (B470e) Enable or disable the scroll lock.
Fn+PrtSc Activate the system request.
Fn+Home Activate the pause function.
Fn+PgDn (B470e) Activate the insert function.
Fn + up/down arrow Increase or decrease display brightness.
Fn + left/right arrow Increase or decrease sound volume.
Connecting external devices
Your computer has a wide range of built-in features and connection capabilities.
Using a flash media card (not supplied)
Your computer supports the following types of flash media cards:
• Secure Digital (SD) card
• Secure Digital High Capacity (SDHC) card
• MultiMediaCard (MMC)
• Memory Stick (MS)
• Memory Stick PRO (MS PRO)
• xD-Picture (xD) card
Notes:
• Insert ONLY one card in the slot at a time.
• This card reader does not support SDIO devices (e.g., SDIO Bluetooth, etc.).
Removing a flash media card
To remove a flash media card, do the following:
1. Push the flash media card until you hear a click.
2. Gently pull the flash media card out of the media card slot.
Note: Before removing the flash media card, disable it via Windows safely remove hardware and eject
media utility to avoid data corruption.
Connecting a universal serial bus (USB) device
Your computer comes with three USB connectors compatible with USB devices.
Note: When using a high power consumption USB device such as USB ODD, use the external device’s
power adapter. Otherwise, the device may not be recognized, and system shut down may result.
