Replacing a memory module
Note: For this procedure, it helps to lay the computer flat.
To replace a memory module:
Step 1. Remove the computer cover. Refer to “Removing the computer cover”.
Step 2. Locate the memory module connectors. Refer to “Locating components”.
Step 3. Remove the memory module to be replaced by opening the retaining clips as shown.
Step 4. Position the new memory module over the memory connector. Make sure that the notch 1 on the
memory module aligns correctly with the connector key 2 on the system board. Push the memory
module straight down into the connector until the retaining clips close.
Step 5. Reattach the computer cover.
Replacing a hard disk drive
Note: For this procedure, it helps to lay the computer flat.
To replace a hard disk drive:
Step 1. Remove the computer cover. Refer to “Removing the computer cover”.
Step 2. Disconnect the data and power cables from the hard disk drive. 1
