6
User Guide
——— Used to attach a telephone line to your computer. (some models
equipped with this connector)
—— Voltage: selection switch (Some models are equipped with this
switch)
Check the position of the voltage-selection switch on the rear of the computer. Use
a ballpoint pen to slide the switch, if necessary.
1. If the voltage supply range is 100-127 V ac, set the switch to 115 V.
2. If the voltage supply range is 200-240 V ac, set the switch to 230 V.
115
23
0
Figure 1 Figure 2
1.3 Speaker (some models equipped with Speaker)
[Y-3]
[Y-1]
[Y-2]
[Y-4]
[Y-5]
[Y-6]
Side elevation Back elevation
