Introduction

The

Secure

Managed

Client

(SMC)

-

Storage

Array

is

designed

to

support

cabinets

that

are

19

inches

(48.26

cm)

wide

by

36

inches

(91.44

cm)

deep.

A

set

of

rack

mounting

rails

is

provided

in

this

kit

and

will

accommodate

either

square

or

round

hole

rack-mounting

methods.

When

mounting

the

storage

system

into

a

cabinet,

the

front

mount

brackets

are

attached

to

the

front

of

the

chassis

and

a

set

of

rear

support

brackets

are

attached

to

the

back

of

the

cabinet.

This

allows

the

weight

of

the

system

to

be

as

evenly

distributed

as

possible.

Tools

needed

The

following

tools

are

needed

to

install

the

SMC

-

Storage

Array

into

a

rack:

v

#2

Phillips

screwdriver

v

A/F

Hex

driver

Kit

contents

The

rail

kit

contains

the

following:

Item

Quantity

Rail

2

Installation

Guide

1

Washer

(tapped

hole)

8

Washer

(square

hole)

8

Washer

(round

hole)

8

M5

12

screw

(round

or

square

hole)

8

10-32

Phillips

screw

(tapped

hole)

8

Allen

hex

key

driver,

10-mm

(tapped

hole)

1

©
