39
Lenovo IdeaPad Yoga 11
1050 Battery pack
For access, remove these FRUs in order:
• “1020 Keyboard” on page 33
• “1030 Keyboard bezel” on page 35
• “1040 Screen rotation lock button board” on page 37
DANGER
Only use the battery specified in the parts list for your computer. Any other battery
could ignite or explode.
Figure 5. Removal steps of battery pack
Detach the battery pack connector in the direction shown by arrow 1 , remove
three screws 2 .
2
2
2
1
Step Screw (quantity) Color Torque
2
M2.0 × 3.0 mm, flat-head, nylok-coated (3) black 1.5-2.0 kg-cm
