LPe16000 Series HBA Installation Manual P007648-01A Rev. A
2. Installation
Viewing the LEDs
15
Table 2-2 POST Conditions and Results
Green LED Yellow LED State
Off Off Boot failure (Dead board)
Off On POST failure (Dead board)
Off Slow Blink Boot failure after POST
Off Fast Blink Not Defined
Off Flashing POST processing in progress
On Off Failure in Common Code Module
On On Failure in Common Code Module
On 1 Fast Blinks Normal (Link up at 2GFC) (legacy compatibility only)
On 2 Fast Blinks Normal (Link up at 4GFC)
On 3 Fast Blinks Normal (Link up at 8GFC)
On 4 Fast Blinks Normal (Link up at 16GFC)
On Flashing Not Defined
Slow Blink Off Normal-link down
Slow Blink On Not Defined
Slow Blink Slow Blink Not Defined
Slow Blink Fast Blink Not Defined
Slow Blink Flashing Not Defined
Fast Blink Off Not Defined
Fast Blink On Not Defined
Fast Blink Slow Blink Not Defined
Fast Blink Fast Blink Beaconing
Fast Blink Flashing Not Defined
