Remove the LCD unit in the direction shown by the arrow 2 .
2
1200 Speaker assembly
For access, remove these FRUs in order:
•
“1010 Battery pack” on page 44
• “1020 Bottom slot cover” on page 44
• “1030 Optical drive” on page 45
• “1040 Memory modules” on page 46
• “1050 Hard disk drive assembly” on page 47
• “1060 PCI Express Mini Card for wireless LAN” on page 49
• “1070 mSATA solid-state drive” on page 51
• “1080 Backup battery” on page 52
• “1090 Keyboard” on page 53
• “1100 Keyboard bezel” on page 55
• “1130 Microphone assembly” on page 60
• “1140 I/O board” on page 61
• “1150 System board assembly and USB board” on page 62
• “1160 DC-in connector” on page 65
• “1190 LCD unit” on page 69
Chapter 7 . Removing and replacing a FRU 71
