32
Chapter 6. Upgrading and replacing devices
6
Pull the tab in the direction shown by arrow .
7
Take out the hard disk drive secured in a metal frame .
8
Remove the screws and detach the metal frame from the hard disk drive.
9
Attach the metal frame to a new hard disk drive; then tighten the screws.
0
Put the hard disk drive gently into the hard disk drive bay with the tab facing upwards and
the connectors facing each other; then push it firmly into space.
A
Reinstall the cover of the hard disk drive slot.
B
Reinstall the screws.
C
Reinstall the battery pack.
D
Turn the computer over again. Connect the AC adapter and the cables to the computer
again.
c
c
d
d
