Antunes, AJ VS-200aSb - Manual (Page 21)

21
Variety SteaMer
P/N 1010649 Rev. E 03/07
water pressure regulator Kit - part no. 7000314
1 003849 bracket 1
2 2040130 Male adapter, barbed 1/4” 2
3 See page 14 for Strainer Parts identification
4 2170113 Regulator, Pressure 1
2170114 gauge, Water Pressure 1
6 2190129 Nipple, 1/4” NPt x 1/4” NPt 1
7 2110104 clamp, worm drive (not shown) 2
3
6
4
1
2
replacement parts (continued)
Item part Description Qty.
no.
64 040P111 snap bushing 1
6 32P104* flat Washer 1/4” 1
66 003989 bracket, Hi-Limit 1
67 see page 13 for strainer Parts identification
68 32P169* bolt, shoulder /16” x 1/2”
1
69 212P120* spacer, st. stl. 1
70 212P118* flat, Washer st. stl. 1
71 32P14* Wash, 1/4” spring Lock 1
72 32P102* Nut, Hex 1/4” - 20 1
73 002101 Lock Lever Weldment 1
Item part Description Qty.
no.
Item part Description Qty.
no.
