Mechanical, Ac-2 – Sheffer LA SERIES User Manual
Page 3
L SERIES
LB SERIES
LS SERIES
ITEM
QUANTITY
NUMBER
DESCRIPTION
NUMBER
REQUIRED
78
LIMIT SW. MTG. SCREW
*
2
85
HOUSING SEAL
*
1
87
ACTUATOR ASSEMBLY
*
1
88
ADAPTER
698-54316
1
94
ADJUSTING SCREW
*
1
95
BOX SEAL
*
1
96
PLUG
*
1
97
GROUND SCREW
*
1
128
JAM NUT
698-30058
1
Parts List
ITEM
QUANTITY
NUMBER
DESCRIPTION
NUMBER
REQUIRED
74
PLUNGER
*
1
76
JUNCTION BOX ASSEMBLY
*
1
76A
JUNCTION BOX COVER
*
1
76B
JUNCTION BOX
*
1
76C
GASKET
*
1
76D
COVER SCREW
*
2
76E
COVER SCREW
*
2
77
LIMIT SWITCH
*
1
77A
SWITCH
698-30002
1
*Model number and serial number are required when ordering this part.
HARDENED CAM
(CUSHION PISTON ON
CUSHIONED FRONT
CYLINDERS)
LIMIT SWITCH ACTUATORS - PARTS LIST
Mechanical
128
87
85
74
78
76B
77
128
85
76C
76D
76A
96
74
95
88
94
97
77A
85
76E
74
AC-2
