Page 26
2-10
Hardware Setup
MS-96E3
Hardware Setup
MS-96E3
LAN
The standard RJ-45 LAN jack s for connec-
ton to the Local Area Network (LAN). You
can connect a network cable to t.
LED
Color
LED State
Condton
Left
Yellow
Off
LAN lnk s not establshed.
On (steady)
LAN lnk s establshed.
On (blnkng)
The computer s communcatng wth another computer on the LAN.
Rght
Green
Off
10 Mbt/sec data rate s selected.
On
100 Mbt/sec data rate s selected.
Orange
On
1000 Mbt/sec data rate s selected.
LAN Bypass Function Programming Guide
96E3 uses the Southbrdge ICH7 GPIO to control CPLD to realze LAN Bypass/
PassThrough/WDT functon.
▶
Yellow
Green/ Orange
