13-
MSI Z97 PLATFORM OC SETTING
REFERENCE TABLE
Note:
The reference value above is for Core i7-4770K ES Processor.
Increasing voltage may raise the success rate of overclocking as the risk of damage the
CPU; thus,we suggest use the special design CPU cooler set to prevent the CPU from
overheating.
Below voltage value would cause the damage of component while under air cooling.
* CPU Voltage:1.6V
* CPU Ring Voltage: < Vcore Voltage
* DRAM Voltage:1.9V
We suggest disable some item in BIOS,such as Phase Control and OverSpeed Protection ,
but EIST、Turbo Boost
If you disable OVP、OCP Function, motherboard or CPU might be damaged.
Tuning Item Default Increment Basic Advanced High
Segment Extreme LN2
CPU Ratio 35 1 35~40 40~45 45~50 >50
CPU Vcore
Voltage (V) 0.8~1 0.001 ~Auto 1~1.3 1.3~1.5 >1.6
Memory
Frequency (MHz) DDR3-
1333/1600 Depends on
DRAM Ratio
& BCLK DDR3-
1333~2400 DDR3-
400~2666 DDR3-
2666~3000 > DDR3-3000
RAM Voltage (V) 1.500 0.01 1.5~1.65 1.65 1.65 >1.65 / <2.0
CPU SA Voltage
(V) 0.85 0.001 Auto 1.0~1.1 1.1~1.25 1.20~1.4
I/O Analog
Voltage (V) 0.8 0.001 Auto 1.0~1.1 1.1~1.25 1.20~1.4
I/O Digital Voltage
(V) 1.0 0.001 Auto 1.0~1.1 1.1~1.25 1.20~1.4
GT
Frequency(MHz) 1250 50 1250~1400 1400~1500 1500~1650 >1750
GT Voltage (V) 0.001 0.001 Auto~0.8 0.8~1.1 1.1~1.2 >1.3
