3-12

BIOS Setup

MS-7549

BIOS Setup

MS-7549

RAID Mode

Ths tem allows you to configure RAID mode for onboard SATA devces.

I/O Devces

Press to enter the sub-menu and the followng screen appears:

COM Port 1

Select an address and correspondng nterrupt for the first seral port.

Parallel Port

There s a bult-n parallel port on the on-board Super I/O chpset that provdes

Standard, ECP, and EPP features. It has the followng optons:

[Dsabled]

[3BC]

Lne Prnter port 0

[278]

Lne Prnter port 2

[378]

Lne Prnter port 1

Parallel Port Mode

[Normal]

Standard Parallel Port

[EPP]

Enhanced Parallel Port

[ECP]

Extended Capablty Port

[ECP + EPP]

Extended Capablty Port + Enhanced Parallel Port

[B-Drectonal]

To operate the onboard parallel port as Standard Parallel Port only, choose [Normal].

To operate the onboard parallel port n the EPP mode smultaneously, choose

[EPP]. By choosng [ECP], the onboard parallel port wll operate n ECP mode only.

Choosng [ECP + EPP] wll allow the onboard parallel port to support both the ECP

and EPP modes smultaneously.
