2-12
Hardware Setup
▍
MS-7549 Hardware Setup
▍
MS-7549
Seral ATA Connector: SATA1~6
Ths connector s a hgh-speed Seral ATA nterface port. Each connector can connect
to one Seral ATA devce.
Floppy D MSIFloppy D
MSI
Kdkl kdkfk kkfdkkl ddfkkksd d fddf asdka df - d dfdd addfdfdddd dfadf adkjasjdkdf dfasd ddffasdfdd dddd dfdasfdasas df asd asd asdddddddfas asdfsdffsdf adfffasdfff df
Floppy D MSI
Kdkl kdkfk kkfdkkl ddfkkksd d fddf asdka df - d dfdd addfdfdddd dfadf adkjasjdkd fdfasd ddffasdfddd ddd dfdasfdasas df asd asd asdddddddfas asdfsdffsdf adfffasdfffd f
Important
Please do not fold the Seral ATA cable nto 90-degree angle. Otherwse, data loss may
occur durng transmsson.
Fan Power Connectors: CPUFAN1, SYSFAN1
The fan power connectors support system coolng fan wth +12V. When connectng the
wre to the connectors, always note that the red wre s the postve and should be con-
nected to the +12V; the black wre s Ground and should be connected to GND. If the
manboard has a System Hardware Montor chpset on-board, you must use a specally
desgned fan wth speed sensor to take advantage of the CPU fan control.
1.Gro
und
2.+1
2V
3.Se
nsor
4.Co
ntrol
1.Gro
und
2.+1
2V
3.Se
nsor
CPUFAN1 SYSFAN1
Important
Please refer to the recommended CPU fans at processor’s offical webste or consult
the vendors for proper CPU coolng fan.
CPUFAN1 supports fan control. You can nstall Dual Core Center utlty that wll auto-
matcally control the CPU fan speed accordng to the actual CPU temperature.
Fan cooler set wth 3 or 4 pns power connector are both avalable for CPUFAN1.
SYSFAN1 support fan control, too. You may select how percentage of speed for the
SYSFAN1 n BIOS.
•
•
•
•
