BIOS Setup MS-7750
Chapter 2
2-13
BIOS Setup MS-7750
Chapter 2
The greater the Spread Spectrum value s, the greater the EMI s reduced, and the
system wll become less stable. For the most sutable Spread Spectrum value, please
consult your local EMI regulaton.
Remember to dsable Spread Spectrum f you are overclockng because even a slght
jtter can ntroduce a temporary boost n clock speed whch may just cause your over-
clocked processor to lock up.
VDroop Control
Load lne droop controls the stream of current to the CPU.
[Auto] Automatcally sets values for maxmum stablty.
[Low VDroop] Provdes less fluctuaton (better for overclockng).
CPU Core Voltage/ DRAM Voltage/ PCH 1.05
These tems are used to adjust the voltage of CPU, Memory and chpset.
Current CPU Core Voltage/ Current DRAM Voltage
These tems show current CPU core/ DRAM voltage. Read-only.
Overclockng Profiles
Press to enter the sub-menu.
Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Press to enter the sub-menu.
Set Name for Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
Save Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Save the current overclockng settngs to ROM for selected profile.
Load/ Clear Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Load/ Clear the stored profile settngs from ROM.
Overclockng Profile Save
Save the current overclockng settngs to USB drve.
Overclockng Profile Load
Load the stored settngs from USB drve.
CPU Specficatons
Press to enter the sub-menu. Ths sub-menu hghlghts all the key features of
your CPU. The nformaton wll vary by model and s read-only. You can also access ths
nformaton at any tme by pressng [F4].
CPU Technology Support
Press to enter the sub-menu. The sub-menu shows the nstalled CPU tech-
nologes. Read only.
MEMORY-Z
Press to enter the sub-menu. Ths sub-menu hghlghts all the settngs and tm-
ngs of your DIMMs. Ths nformaton wll vary by model and s read-only. You can also
access ths nformaton at any tme by pressng [F5].
•
•
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
