1-9
MS-7750
Chapter 1
HDMI Port
The Hgh-Definton Multmeda Interface (HDMI) s an all-dgtal audo-vdeo nterface
that s capable of transmttng uncompressed streams. HDMI supports all types of TV
formats, ncludng standard, enhanced, or hgh-definton vdeo, plus mult-channel
dgtal audo on a sngle cable.
VGA Port
The DB15-pn female connector s provded for montor.
DVI-D Port
The DVI-D (Dgtal Vsual Interface- Dgtal) connector can be connected to a LCD montor.
To connect a montor, please refer to the montor’s manual for more nformaton.
Important
The HDMI, VGA and DVI-D dsplay ports are desgned to be used by the Integrated
Graphcs Processor (IGP). If the processor nstalled does not provde ntegrated
graphcs, these dsplay ports wll not functon.
LAN
The standard RJ-45 LAN jack s for connectng to a
Local Area Network (LAN).
LED Color LED State Condton
Left Yellow Off LAN lnk s not establshed.
On(Steady) LAN lnk s establshed.
On(flashng) The computer s communcatng wth another computer on the network.
Rght Green Off 10 Mbts/sec data rate
On 100 Mbts/sec data rate
Orange On 1000 Mbts/sec data rate
Audo Ports
These connectors are used for audo devces. The color of the jack refers to the functon
of the connector.
Blue-Lne n: Used for connectng external audo outputtng devces.
Green- Lne out: Used as a connector for speakers or headphone.
Pnk- Mc: Used as a connector for a mcrophone.
Black- RS-Out: Rear surround sound lne out n 4/ 5.1/ 7.1 channel mode.
Orange- CS-Out: Center/ subwoofer lne out n 5.1/ 7.1 channel mode.
Gray- SS-Out: Sde surround sound lne out n 7.1 channel mode.
▶
▶
▶
▶
▶
■
■
■
■
■
■
Yellow Green/ Orange
