Jumper

Clear CMOS Jumper: JBAT1

There s CMOS RAM onboard that s external powered from a battery located on the

motherboard to save system configuraton data. Wth the CMOS RAM, the system can

automatcally boot nto the operatng system (OS) every tme t s turned on. If you want

to clear the system configuraton, set the jumpers to clear the CMOS RAM.

JBAT1

Keep Data

Clear Data

1

1

1

Important

You can clear the CMOS RAM by shortng pns 2 and 3 whle the system s off. After-

wards, return the jumpers to the 1 and 2 poston. Do not clear the CMOS RAM whle

the system s on because t wll damage the motherboard.
