3-8
BIOS Setup MS-7676
Chapter 3
BIOS Setup MS-7676
Chapter 3
Intel Turbo Booster
Ths tem wll appear when you nstall a CPU wth Intel Turbo Boost technology. Ths
tem s used to enable/ dsable Intel Turbo Boost technology. It can scale processor
frequency hgher dynamcally when applcatons demand more performance and TDP
headroom exsts. It also can delver seamless power scalablty (Dynamcally scale up,
Speed-Step Down). It s the Intel newly technology wthn newly CPU.
OC Gene Button Operaton
Ths field s used to enable/ dsable OC Gene functon.
DRAM Frequency
Ths settng controls the frequency of memory.
Adjusted DRAM Frequency
It shows the adjusted DRAM frequency. Read-only.
DRAM Tmng Mode
Select whether DRAM tmng s controlled by the SPD (Seral Presence Detect)
EEPROM on the DRAM module. Settng to [Auto] enables DRAM tmngs and the
followng “Advanced DRAM Configuraton” sub-menu to be determned by BIOS based
on the configuratons on the SPD. Selectng [Lnk] or [Unlnk] allows users to configure
the DRAM tmngs and the followng related “Advanced DRAM Configuraton” sub-menu
manually.
Advanced DRAM Configuraton
Press to enter the sub-menu.
Command Rate2
Ths settng controls the DRAM command rate.
tCL
Ths controls the CAS latency, whch determnes the tmng delay (n clock cycles)
before SDRAM starts a read command after recevng t.
tRCD
When DRAM s refreshed, both rows and columns are addressed separately. Ths
setup tem allows you to determne the tmng of the transton from RAS (row ad-
dress strobe) to CAS (column address strobe). The less the clock cycles, the faster
the DRAM performance.
▶
▶
▶
▶
▶
▶
▶
▶
▶
