Chapter 1 – MSI 880G-E45 User Manual

Page 13

1-3

MS-7576

Chapter 1

Connectors

Back panel

1 PS/2 port

1 Optical S/PDIF-Out port

1 VGA port

1 DVI-D port

1 HDMI port

1 IEEE1394 port (optional)

6 USB 2.0 ports

1 eSATA port

1 LAN jack

6 flexible audio jacks

On-Board Connectors

3 USB 2.0 connectors

1 IEEE1394 connector (optional)

1 SPDIF out connector

1 CD-In connector

1 Front Panel Audio connector

1 Chassis Intrusion Switch connector

1 Serial connector

1 TPM connector

1 OC switch

1 Power LED Button

1 Reset LED Button

1 Clear CMOS Button

Slots

1 PCI Express x16 slot

3 PCI Express x1 slots

2 PCI slot, support 3.3V/ 5V PCI bus Interface

Form Factor

ATX (30.5cm X 24.4 cm)

Mounting

9 mounting holes

* If you need to purchase accessories and request the part numbers, you could search

the product web page and find details on our web address below
http://www.msi.com/index.php

■
