CPU Core OCP Expander
Ths tem s used to expand the lmtaton of CPU core OCP (Over Current Protecton).
The hgher expandng value ndcates less CPU protecton. So please adjust the CPU
core voltage carefully f needed.
CPU NB Core OCP Expander
Ths tem s used to expand the lmtaton of CPU-NB OCP (Over Current Protecton).
The hgher expandng value ndcates less CPU-NB protecton. So please adjust the
CPU-NB voltage carefully f needed.
CPU Voltage/ CPU-NB Voltage/ DRAM Voltage/ CPU_VDD1_2 Voltage/ VCC1P1
Voltage/ MEM_VREFA_CA/ MEM_VREFB_CA/ MEM_VREFA_DQ/ MEM_VREFB_DQ/
+1.1VDUAL/ VCCA_25
These tems are used to adjust the voltages.
Spread Spectrum
Ths functon reduces the EMI (Electromagnetc Interference) generated by modulatng
clock generator pulses.
Important
If you do not have any EMI problem, leave the settng at [Dsabled] for optmal system
stablty and performance. But f you are plagued by EMI, select the value of Spread
Spectrum for EMI reducton.
The greater the Spread Spectrum value s, the greater the EMI s reduced, and the
system wll become less stable. For the most sutable Spread Spectrum value, please
consult your local EMI regulaton.
Remember to dsable Spread Spectrum f you are overclockng because even a slght
jtter can ntroduce a temporary boost n clock speed whch may just cause your
overclocked processor to lock up.
Overclockng Profiles
Press to enter the sub-menu.
Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Press to enter the sub-menu.
Set Name for Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
Save Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Save the current overclockng settngs to ROM for selected profile.
Load/ Clear Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Load/ Clear the stored profile settngs from ROM.
OC Profile Save to USB
Save the current overclockng settngs to USB flash dsk.
OC Profile Load from USB
Load the stored settngs from USB flash dsk.
▶
▶
▶
▶
•
•
•
▶
▶
▶
▶
▶
▶
▶
