Gettng Started
Poston the coolng set onto the
retenton mechansm.
Hook one end of the clp to hook
first.
5. Then press down the other end of the
clp to fasten the coolng set on the
top of the retenton mechansm.
Locate the Fx Lever and lft up t .
6.
Fasten down the lever. 7. Attach the APU Fan cable to the APU
fan connector on the manboard.
8.
Important
Whle dsconnectng the Safety Hook from the fixed bolt, t s necessary to keep an
eye on your fingers, because once the Safety Hook s dsconnected from the fixed
bolt, the fixed lever wll sprng back nstantly.
Confirm that the APU cooler has formed a tght seal wth the APU before bootng
your system.
Please refer to the documentaton n the APU cooler package for more detals about
APU cooler nstallaton.
•
•
•
