1-27
MS-7793
Chapter 1
JCI1: Chasss Intruson Connector
Ths connector connects to the chasss ntruson swtch cable. If the computer case s
opened, the chasss ntruson mechansm wll be actvated. The system wll record ths
ntruson and a warnng message wll flash on screen. To clear the warnng, you must
enter the BIOS utlty and clear the record.
1.CIN
TRU
2.Gro
und
JTURBO1: MultConnect Panel Connector
Ths connector s used to connect an optonal front panel for controlng the OC Gene and
some addtonal functons. Please refer to ts user gude for more detals and usages.
3.TU
RBO
4.No
Pin
2.Co
ntrol
Pin
1.TU
RBO
