Chapter 1
1-9 Getting Started
PS/2 Keyboard/Mouse Combo Port
A combination of PS/2 ® mouse/keyboard DIN connector for a PS/2 ® mouse/keyboard.
USB 2.0 Port
The USB 2.0 port is for attaching USB 2.0 devices such as keyboard, mouse, or other
USB 2.0-compatible devices.
VGA Port
The DB15-pin female connector is provided for monitor.
DVI-D Port
The DVI-D (Digital Visual Interface- Digital) connector can be connected to a LCD
monitor, or a CRT monitor with an adapter. To connect a monitor, please refer to the
monitor’s manual for more information.
HDMI Port (For H81I)
®
The High-Definition Multimedia Interface (HDMI) is an all-digital audio-video interface
that is capable of transmitting uncompressed streams. HDMI supports all types of TV
formats, including standard, enhanced, or high-definition video, plus multi-channel
digital audio on a single cable.
Important
This platform supports dual-display function.
Dual-display mode
VGA+DVI-D/
DVI-D+HDMI/
HDMI+VGA
Extend mode
(Extend the desktop to the other monitor)
◯
Clone mode
(Monitors have the same screen)
◯
Optical S/PDIF-Out
This S/PDIF (Sony & Philips Digital Interconnect Format) connector is provided for
digital audio transmission to external speakers through an optical fiber cable.
▶
▶
▶
▶
▶
▶
