Chapter 1
1-5 Getting Started
Internal
Connectors
1x 24-pin ATX main power connector
1x 4-pin ATX 12V power connector
4x SATA connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x Clear CMOS jumper
1x Front panel audio connector
2x System panel connectors
1x Serial port connector
1x TPM connector
1x Chassis Intrusion connector
■
■
■
■
■
■
■
■
■
■
■
■
■
I/O
Controller
NUVOTON NCT5533 Controller Chip ■
Hardware
Monitor
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control
■
■
■
BIOS
Features
64 Mb flash
UEFI AMI BIOS
ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
Multi-language
■
■
■
■
Special
Features
Military Class 4
OC Genie 4
Click BIOS 4
Total Fan Control
Command Center
■
■
■
■
■
Software Drivers
MSI
Command Center
Super Charger
Live Update 5
Fast Boot
7-ZIP
Intel Extreme Tuning Utility
Norton Internet Security Solution
Trend Micro SafeSync
Network genie
■
■
-
-
-
-
■
■
■
■
■
Form
Factor
Mini-ITX Form Factor
6.7 in. x 6.7 in. (17 cm x 17 cm)
■
■
For the latest information about CPU, please visit
http://www.msi.com/service/cpu-support/
For more information on compatible components, please visit
http://www.msi.com/service/test-report/
