Motherboard Specifications
CPU
Support
4th Generation Intel ® Core™ i7 / Core™ i5 / Core™ i3 / Pentium ® /
Celeron ® processors for LGA 1150 socket
■
Chipset Intel ® H81 Express Chipset ■
Memory
Support
2x DDR3 memory slots supporting up to 16GB
Supports DDR3 1600/ 1333/ 1066 MHz
Dual channel memory architecture
Supports non-ECC, un-buffered memory
Supports Intel ® Extreme Memory Profile (XMP)
■
■
■
■
■
Expansion
Slot
1x PCIe 2.0 x16 slot ■
Onboard
Graphics
1x VGA port, supports the maximum resolution of 1920x1200 @
60Hz, 24bpp
1x DVI-D port, supports the maximum resolution of 1920x1200 @
60Hz, 24bpp
1x HDMI port, supports the maximum resolutions of
2560x1600@60Hz, 24bpp/ 1920x1080@60Hz, 36bpp*
* For H81I only.
■
■
■
Storage Intel H81 Express Chipset
2x SATA 6Gb/s ports (SATA1~2)
2x SATA 3Gb/s ports (SATA3~4)
■
-
-
USB Intel H81 Express Chipset
2x USB 3.0 ports (2 ports available through the internal USB 3.0
connector)
6x USB 2.0 ports (2 ports on the back panel, 4 ports available
through the internal USB 2.0 connectors)*
8x USB 2.0 ports (4 ports on the back panel, 4 ports available
through the internal USB 2.0 connectors)**
* For H81I only.
** For H81I-S01 only.
■
-
-
-
RENESAS UPD720202 chip
2x USB 3.0 ports (2 ports on the back panel)*
* For H81I only.
■
-
Audio Realtek ® ALC887 Codec
7.1-Channel High Definition Audio
Supports S/PDIF output
■
-
-
LAN Realtek ® RTL8111G Gigabit LAN controller ■
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
2x USB 2.0 ports, 2x USB 3.0 ports (for H81I)
4x USB 2.0 ports (for H81I-S01)
1x VGA Port
1x DVI-D port
1x HDMI port (for H81I)
1x Optical S/PDIF-OUT connector
1x LAN (RJ45) port
3x audio jacks
■
■
■
■
■
■
■
■
■
