18. [RUP=]
This command ramps the output volume to a
user defined level at a rate defined using the
[RAMP] command.
Command Format: [RUP=xxCnUi]
xx = Stop Level (xx = # from 01-32)
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
Ramp the output volume from a starting level of
1 to a level of 20 for the card in slot 4. Send the
command [RUP=20C4] and the system will
respond with the following feedback:
[02][03][04]…[20]
19. [RDN]
This command ramps the output volume down
to a level of 1 at a rate defined using the
[RAMP] command.
Command Format: [RDNCnUi]
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
Ramp the output volume from a starting level of
32 down to 1 for the card in slot 4. Send the
command [RDNC4] and the system will respond
with the following feedback:
[31][30][29]…[01]
20. [RDN=]
This command ramps the output volume down
to a user defined level at a rate defined using
the [RAMP] command.
Command Format: [RDN=xxCnUi]
xx = Stop Level (xx = # from 01-32)
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
Ramp the output volume from a starting level of
32 down to 16 for the card in slot 4. Send the
command [RDN=16C4] and the system will
respond with the following feedback:
[31][30][29]…[16]
21. [RAMP]
This command displays the ramping time for 32
steps. The time between each step is equal to
the time in seconds divided by 32.
Command Format: [RAMPCnUi]
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
Display the ramp rate setting for the card in
slot 4 by sending the command [RAMPC4]. The
system will respond with feedback similar to the
following:
RAMPTIME = 6 SECONDS
22. [RAMP=]
This command sets the ramp rate for 32 steps.
The settings range from 4 to 18 seconds, in
two-second intervals.
Command Format: [RAMP=xCnUi]
x = Rate in Seconds
4 = 0.13 seconds/step
6 = 0.19 seconds /step
8 = 0.25 seconds /step
10 = 0.31 seconds /step
12 = 0.38 seconds /step
14 = 0.44 seconds /step
16 = 0.50 seconds /step
18 = 0.56 seconds /step
Cn = Card ID (n = # from 1 to max slots)
Ui
= Unit ID (i = # from 0 to 9)
