Chapter 1
1-26 Getting Started
JUSB1~2: USB 3.0 Expansion Connector
The USB 3.0 port is backwards compatible with USB 2.0 devices. It supports data
transfer rates up to 5Gbits/s (SuperSpeed).
5.U
SB
3_T
X_
C_
DN
4.G
rou
nd
3.U
SB
3_R
X_
DP
2.U
SB
3_R
X_
DN
1.P
ow
er
10.
Gro
und
9.
+
US
B2
.0
8.
-
US
B2
.0
7.G
rou
nd
6.U
SB
3_T
X_
C_
DP
20.
No
Pin
19.
Po
we
r
18.
US
B3
_R
X_
DN
17.
US
B3
_R
X_
DP
16.
Gro
und
15.
US
B3
_T
X_
C_
DN
14.
US
B3
_T
X_
C_
DP
13.
Gro
und
12.
US
B2
.0
-
11.
+
US
B2
.0
The JUSB1 (red mark) connector supports MSI’s new Super-Charger technology
which provides quicker USB charging of your smartphone or other USB-powered
devices. To enable this feature, please install the MSI Super-Charger application
on your computer. When the Super-Charger application is turned on, the JUSB1
connector will convert data channels to extra power channels to quickly charge your
connected device. Please note that when the Super-Charger application is turned on,
data transmission and synchronization over the JUSB1 connector will not function. To
enable the JUSB1 connector to function as a normal USB 3.0 connector, please turn
off the Super-Charger application. When the computer is in stand-by or hibernation
mode (S3/ S4/ S5) Super-Charger mode will automatically be enabled.
Important
• Note that the VCC and GND pins must be connected correctly to avoid possible
damage.
• To use a USB 3.0 device, you must connect the device to a USB 3.0 port through
an optional USB 3.0 compliant cable.
• Please only connect one device per USB port to ensure stable charging.
• Super-Charger Technology is only available on select MSI motherboard models.
Please refer to the MSI website to check if your motherboard has Super-Charger
technology.
• For iPad, JUSB1 (red mark) can still charge iPad in S3, S4, S5 state.
• We recommend that don’t disconnect the device when you charge it in S1 state.
