4
Wiring the aMplifier
Step #1: Plug the two connectors of the main wire harness into “Power” and
“Audio Input” on the amplifier. Tighten (snug) the two small flathead
screws on the power connector to prevent it from backing out while riding.
Step #2: On the input harness, locate the yellow/black pair of wires with the
male connectors and plug them into the factory speaker wires on the
clutch side of the bike. Also on the input harness, locate the green/black
pair of wires with the male connectors and plug them into the factory
speaker wires on the brake side of the bike. The connectors are sized
correctly and will only go in one way. NOTE: The blue 4 pin plug with
black wires on the input harness is an “expansion port” which is used to
send music to a second amp or is used to send radio power to run other
speakers on the bike. You can see how the expansion port can be used
further on in this manual.
Step #3: On the opposite side of the amp are 3” (75mm) wires ending with a
4 pin black connector. This plug sends amplified power to your
speakers. Locate the 4 pin black plug wire harness with brown/black
and blue/black wires. Plug it into the amplified output plug. The
blue/black wires will plug directly to the speaker on the brake side of
the bike. The brown/black wires will plug directly to the speaker on the
clutch side of the bike.
Step #5: Separate the Hogtunes speakers from their grills. If you want to use the
supplied steel mesh grills, continue to Step #6. If you want to keep the
stock grill cloth look, take your stock grills and CAREFULLY separate the
factory plastic mesh that holds the grill cloth from the main grill “ring”.
Carefully remove the Hogtunes steel mesh from the Hogtunes ring. Your
factory mesh/grill cloth should have enough “tack” to stick onto the
Hogtunes ring but will be properly secured when the grills are installed.
Step #6: Included in this kit is a bag with six Phillips head screws. Using these
supplied screws, install each 3572-AA grill to the bike and re-install
the stock “speed nut” on each side. Re-attach the 5x7’s to their grills
using the screws you took out in Step 5, noting that the speakers must
be oriented in the grills so the wire connectors are closest to the radio.
DO NOT USE FACTORY SCREWS TO
ATTACH NEW GRILLS TO FAIRING!
