CONTENTS
INTRODUCTION
1-1 General Information
1-2 Application Information
1-3 Specifications
1-4 Dimensions
1-5 Performance
1-6 Wiring Diagram (limit switch models)
INSTALLATION
2-1 Direction of Loading
2-2 Limit Switches
2-3 Wiring Connections
2-4 Limit Switch Adjustment
OPERATION
3-1 Operating Conditions
INSPECTION AND MAINTENANCE
4-1 Safety Note
4-2 Inspection
4-3 Maintenance
4-4 Lubrication
WARRANTY
3
3
3
3
4
4
5
5
5
5
5
5
5
5
5
6
1-1 General Information
This manual provides instructions for the installation
and operation of Duff-Norton® electromechanical
actuators. All persons operating or maintaining
these actuators should be familiar with the informa-
tion presented here.
1-2 Application Information
This actuator is designed to provide linear actuation
of guided loads requiring forces no greater than the
load rating of the actuator. It is intended for inter-
mittent use, not for applications requiring constant
motion. The actuator should not be used to lift,
support, or otherwise transport people unless the
application is authorized in writing by Duff-Norton.
The actuator can be used outdoors but must not be
subjected to precipitation, high pressure sprays,
icing, or submersion. Do not use the actuator in
areas containing explosive dust, vapors, or gases.
INTRODUCTION
EM-1010-100_0706 7/31/07 2:40 PM Page 1
