Autostart AS-2350vTW-FM User Manual
Page 13
User Guide
P. 13
STATUS
SEQUENCE
LED #1
LED #2
LED #3
LED #4
Beep(s)
1
st
sequence if
unlocked
X 3
flashes X
X
2
2
nd
sequence
1 second
X
X
1 second
X
1
st
sequence if
locked
3 flashes
X
X
X
1
1
st
sequence if
unlocked
X 3
flashes X
X
1
Valet
Mode
2
nd
sequence
1 second
X
X
1 second
X
Table 1
Ready Mode Status Request
STATUS
SEQUENCE
LED #1
LED #2
LED #3
LED #4
Beep(s)
if locked
3 flashes
X
X
X
1
In Ready
Mode
if unlocked
X 3
flashes X
X
2
1
st
sequence
if locked
3 flashes
X
X
X
1
1
st
sequence
if unlocked
X 3
flashes X
X
2
Out of Ready
Mode
2
nd
sequence
X X X 4 4
Table 2
Status Request When the Engine is Running
When the vehicle doors are locked:
The LED # 1 will flash 3 times to denote that the vehicle’s doors are locked.
When the vehicle doors are unlocked:
The LED # 2 will flash 3 times to denote that the vehicle’s doors are unlocked.
RUN TIME
Beep(s)
LED #1
LED #2
LED #3
LED #4
If there is more than 3/4 of run
time cycle
3
ON for 1-sec ON for 1-sec ON for 1-sec ON for 1-sec
If there is more than half of
run time cycle
3
ON for 1-sec ON for 1-sec ON for 1-sec
X
If there is more than 1/4 of run
time cycle
3
ON for 1-sec ON for 1-sec
X
X
If there is less than 1/4 of run
time cycle
3
ON for 1-sec
X
X
X
Table 3
