P. 12 User Guide
Option 3:
Level 1 (requires pressing the SHIFT button 1X) Æ Customized features
Level 2 (requires pressing the SHIFT button 2X) Æ Multi car operation
Level 3 (requires pressing the SHIFT button 3X) Æ Basic features
Option 4:
Level 1 (requires pressing the SHIFT button 1X) Æ Basic features
Level 2 (requires pressing the SHIFT button 2X) Æ Customized features
Level 3 ( requires pressing the SHIFT button 3X) Æ Multi car operation
Example: If the multi-level features have been modified from their default state to option 3, the
setup would be as follows:
For “Basic features”:
x
To access the aux. 2 feature, the user needs to press on the SHIFT button three (3) times
followed by the LOCK button.
x To access the status request feature, the user needs to press on the SHIFT button three (3)
times followed by the TRUNK button.
x To access cold weather mode, the user needs to press on the SHIFT button three (3) times
followed by the START/STOP button..
Vehicle Status Request
The status request feature allows the user to see the status of the vehicle i.e.: if the doors are
locked or unlocked or if the vehicle is in cold weather mode, home valet mode, in valet mode or
how much time is left in the run time cycle. The following charts (Tables 1, 2 and 3) indicate the
confirmation sequences.
To retrieve the vehicle status:
Press and release the
SHIFT button then press and release the TRUNK button (there will be a beep).
The transmitter will then flash the corresponding sequence of LEDs depending on the vehicle’s
status.
x If the engine is NOT running, refer to Table 1.
x If the vehicle is in or out of ready mode, refer to Table 2
x If the engine IS running under a remote start, refer to Table 3 (if the doors are locked)
or refer to Table 4 (if the doors are unlocked).
The status request feature is a two-step procedure:
• The first sequence of flashes denotes if the vehicle’s doors are locked or unlocked.
• The second sequence of flashes (if applicable) denotes if the vehicle is in Cold weather mode,
Home valet mode or Valet mode.
• If there is no second sequence transmission, then the vehicle is none of the three (3) mentioned
features (Cold weather mode, Home valet mode or Valet mode).
Status Request When the Engine IS NOT Running
STATUS SEQUENCE LED #1 LED #2 LED #3 LED #4 Beep(s)
Lock 3 flashes X X X 1
Unlock X 3 flashes X X 2
1 st sequence if
locked
3 flashes X X X 2
1 st sequence if
unlocked
X 3 flashes X X 2
Cold
Weather
2 nd sequence X X X 1 second X
Home
Valet
1 st sequence if
locked
3 flashes X X X 2
