8 PCM-9570/S User's Manual
2.1 Jumpers
The PCM-9570/S has a number of jumpers that allow you to
configure your system to suit your application. The table below lists
the function of each of the board’s jumpers:
Table 2-1: Jumpers
Label Function
J1 CMOS clear
J2 Watchdog timer action
J3 SCSI terminator power enable/disable
J4 ATX power switch button
J6 COM port RI pin setting
J7 PanelLink control
J9 Buzzer enable/disable
J10 COM2 RS-232/422/485 setting
J11 ATX power on function select
J12 LAN controller power select
SW1 Panel type select
