C.5 Main power connector (CN6)
Table C-5: Main power connector (CN6)
Pin Signal
1 +12 V
2 GND
3 GND
4 +5 V
C.6 IR connector (CN8)
Table C-6: IR connector (CN8)
Pin Signal
1 V
CC
2 NC
3 IR IN
4 GND
5 IR OUT
5
1
4
3
2
1
4
3
2
