Filter Version
• The air is filtered through a charcoal filter and returned to the kitchen.
• You will need an original AEG charcoal filter for the recirculation
function. (Available from your local AEG Service Force Centre).
• Opening the grid: Move the two sliders towards the centre (in the
“OPEN” direction) and release the grille downwards. Fig. 3
To refit the grid: it should be inserted above between the
appropriate guides until it latches into place, and after having
propped the grille to the cooker hood also in the lower part move the
two sliders outwards (in the “CLOSED” direction). Fig. 3.
• Insert the charcoal filter into the lugs of the frame above using the 2
red lugs E to retain it, press the red lugs inwards, and insert the
charcoal filter in the frame. Fig. 4.
• Refit the grid.
• The deflector F must be fitted over the hole B (Fig. 1) fixing it with
the screw provided. Fig. 5.
Fig. 4 Fig. 3
F
Fig. 5
O
PE
N
CLOSED
O
PE
N
CLOSED
Guides
