Description of the Appliance
• The hood is supplied as an extractor unit and can also be used with
a filtering function by fitting one charcoal filter.
• You will need an original AEG charcoal filter for this function
(Available from your local AEG Service Force Centre).
Extractor version
• In this version fumes are extracted to the outside via a hose
connected to the coupling ring A, placed in the outlet hole B. Fig. 1.
• In order to obtain the best performance the hose should have a
diameter equal to the outlet hole.
• Depending on your installation the hose can be directed either
towards the ceiling or towards the walls. Fig. 2.
Fig. 1
Fig. 2
