WIKA operating instructions air2guide model A2G-40
7
GB
40202771.02 07/2012 GB/D/F/E/I
3. Specifications / 4. Design and function
Permissible temperature
Ambient: -40 ... +85 °C
Operation: -20 ... +60 °C
Accuracy
Low-set switch point: 20 Pa ±5 Pa to 500 Pa ±50 Pa
High-set switch point: 200 Pa ±20 Pa to 4,500 Pa ±200 Pa
Switching differential
10 Pa ... 180 Pa
Service life
> 1,000,000 switching cycles
Ingress protection
IP 54 per EN 60529 / lEC 529
Standards
In accordance with the European low-voltage directive 73/23/EEC
For further specifications see WIKA data sheet SP 69.02 and the order
documentation.
4. Design and function
Description
Through the differential pressure to be measured, an unopposed force
is produced on the diaphragm. This measurement force moves the
diaphragm system against the measuring range spring, and the micro
switch is activated via a switch plunger mounted on the diaphragm.
The switch point can be set on the scaled adjustment wheel.
