KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

6 Technical Specifications

Table 3 includes the technical specifications:

Table 3: Technical Specifications

PORTS:

of the TP-400FW FireWire Range Extender

One Front Panel and Rear Panel 6-pin serial 1394 port

2 RJ45 CAT-5 ports

TRANSFER RATE:

100Mbps

IEEE-1394 STANDARDS: IEEE 1394a-2000, IEEE 1394-1995, IEEE 1394b-2002 @ up to 100Mbps
ESD LINE PROTECTION: IEC 61000-4-2 (ESD) 15kV (air), 8kV (contact), IEC 61000-4-5 (Lightning)

12A (8/20us), and IEC 61000-4-4 (EFT) 40A (5/50ns)

POWER SOURCE:

230 VAC, 50/60 Hz. (115VAC, U.S.A.) 30VA

DIMENSIONS:

22cm x 18cm x 4.5cm (8.7" x 7" x 1.7") W, D, H.

WEIGHT:

1.3 kg (2.9 lbs.) approx.

ACCESSORIES:

Power cord

OPTIONS:

RK 80 19" rack kit

1 Specifications are subject to change without notice
