4 PT-571HDCP/PT-572HDCP+ - Overview
3 Overview
The PT-571HDCP is a DGKat™ twisted pair transmitter for DVI signals. The
PT-571HDCP converts a DVI signal to a single twisted pair signal and the
PT-572HDCP+ converts the twisted pair signal back to a DVI signal.
The DVI Line Transmitter/Receiver system features:

Maximum data rate/bandwidth up to 1.65Gbps, WUXGA, 1920x1080p

HDTV compatibility and HDCP compliance

Medical equipment compliance

EDID PassThru that passes EDID signals between the source and display

3D pass-through

System Range – Up to 90m (295ft) at 1080i, or up to 30m (98ft) at 1080p on
shielded BC-DGKat524 cable; 90m (295ft) at 1080i, or up to 70m (230ft) at
1080p on shielded BC-DGKat623 cable; 100m (330ft) at 1080i or up to 90m
(295ft) at 1080p on shielded BC-DGKat7a23 cable
Note that the transmission range depends on the signal resolution, graphics card and
display used. The distance using non-Kramer CAT 5, CAT 6 and CAT 7a cables may
not reach these ranges
 DGKat™ Signal Integration – Kramer’s unique technology for converting
TMDS as well as control and communication to signals that run over twisted
pair cables
 Power Connect™ that feeds 12V DC over the CAT 5 cable from transmitter
to receiver (see Section
3.2
)

Ultra-
Compact Pico TOOLS™ – 4 units can be rack mounted side−by−side
in a 1U rack space with the optional RK−4PT rack adapter.
Use only shielded cable where both ends of the shield are soldered
to ground to eliminate ESD interface.
