640T/640R - Technical Specifications
6
Technical Specifications
640T
640R
INPUTS:
1 HDMI connector
5 BNC connectors
OUTPUTS:
5 BNC connectors
1 HDMI connector
PORT:
1 IR on a 3.5mm mini connector
MAX. DATA RATE:
Supports up to 6.75Gbps (2.25Gbps per graphic channel)
up to 720p with HDCP
STANDARDS COMPLIANCE:
HDMI and HDCP
POWER SOURCE:
12V DC, 650mA
12V DC, 540mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0"), W, D, H
WEIGHT:
0.3kg (0.7lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
Kramer external remote IR receiver
C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE
Specifications are subject to change without notice a
640T/640R Range Chart
Cable Type
Max Range
BC-5 (28 AWG)
50m
BC-5 (26 AWG)
60m
RG-59
115m
RG-6
150m
