Technical Specifications

6 Technical Specifications

Table 2 includes the technical specifications:

Table 2: Technical Specifications

of the VP-100 VGA/XGA to RGBHV Converter

INPUTS:

Looping analog red, green, blue signals: 0.7Vpp/75 , H and V sync, TTL level,

on HD15F connector

OUTPUTS:

1 x analog red, green (with or without composite sync), blue signals: 0.7Vpp/75 ,

H and V sync, TTL level (Hi-Z load) or analog level (75 load), on BNC

connectors.

Composite sync - TTL level (Hi-Z load) or analog level (75 load)

BANDWIDTH (-3dB): 350MHz
S/N RATIO:

71dB

DIFF. GAIN:

0.07%

DIFF. PHASE:

0.03 Deg.

K-FACTOR:

< 0.05%

CONTROLS:

Cable EQ. control, H and V sync switches and controls, G / sync on green switch,

Hs / Cs switch, ID BIT switch, input termination switch; EQ. control: 0 to +9.7dB

@5MHz

DIMENSIONS:

12cm x 7.15cm x 2.44cm (4.72" x 2.81" x 0.96"), W, D, H

POWER SOURCE:

12 VDC, 60mA

WEIGHT:

0.3kg (0.67lbs.) approx.

ACCESSORIES:

Power supply, mounting bracket

OPTIONS:

19" rack adapters

1 Specifications are subject to change without notice
