Overview
3
3 Overview
The VP-100 VGA/XGA to RGBHV Converter is a high performance format
converter for computer graphics video signals. It converts a computer
graphics video signal on a 15-pin HD connector to either RGBS, RGsB, or
RGBHV video signals on BNC connectors and simultaneously outputs it to
an RGBHV acceptor and a local display.
In particular, the
VP-100:
Provides local monitor loop-through, buffering, amplification, and sync
processing for remote acceptor applications
Accepts all typical graphic modes, including VGA, SVGA, XGA, SXGA,
and UXGA and outputs RGsB, RGBS, or RGBHV
Has a bandwith of 350MHz that ensures transparent operation at multiple
resolutions including UXGA
Allows looping with a termination switch
Includes cable EQ. control, Hs and Vs shift control and ID BIT control
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position
your VP-100 away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit
1
.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 For example: model number AD2512C, part number 2535-000251
