6 technical specifications, Technical specifications – Kramer Electronics FC-46xl User Manual
Page 12
FC-46xl - Technical Specifications
9
6 Technical
Specifications
INPUT: HDMI
Connector
OUTPUTS:
1 HDMI Connector
1 TOSLINK
®
optical digital audio connector
1 S/PDIF digital audio on an RCA connector
1 Analog audio on a 3.5 mm mini connector
OPERATION FREQUENCY:
Supports up to 2.25Gbps (1080p @60Hz) 36 bit Deep
Color
COMPLIANCE WITH HDMI
STANDARD:
Supports HDMI, HDCP
CONTROLS:
Audio Source Select button
INDICATOR LEDS:
ON, IN, OUT
POWER SOURCE:
5V DC, 650mA
OPERATING TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE:
-45° to +72°C (-49° to 162°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.4cm x 7cm x 2.4cm (4.9" x 2.8" x 0.94") W, D, H
WEIGHT:
0.4kg (0.88lbs) approx.
ACCESSORIES: Power
supply
OPTIONS:
Kramer 10-Port Universal 5V Power Supply VA-100P-5
RK-3T 19” rack adapter
Specifications are subject to change without notice at
