6 FC-321 - Defining the FC-321
# Feature Function
1 SD/HD-SDI IN 1
BNC Connector Connects to the SD or HD-SDI source 1
2 SD/HD-SDI IN 2
BNC Connector Connects to the SD or HD-SDI source 2
3 SDI AUDIO GROUP
SELECT Turn to select the input stereo channel (0 to 7)
4 HDMI OUT
Connector Connects to an HDMI acceptor
5 5V DC +5V DC connector for powering the unit
6 REMOTE IR Sensor Receives the input from an IR remote control
7 REMOTE IR LED Flashes red when receiving an IR signal
8 IN SELECT
Pushbutton Press to toggle between SDI 1 IN and SDI 2 IN
9 SDI 1 IN LED Illuminates green for an SD input signal and blue for an HD input
signal on HD-SDI 1
10 OUT LED Illuminates green to indicate that the display is connected
11 SDI 2 IN LED Illuminates green for an SD input signal and blue for an HD input
signal on HD-SDI 2
12 ON LED Illuminates green when receiving power
