FC-321 - Connecting the FC-321 7
7
5 Connecting the FC-321
This section explains how to connect the FC-321.
Always switch off the power to each device before connecting it to your
FC-321. After connecting your FC-321, connect its power and then
switch on the power to each device.
To connect the FC-321, as illustrated in the example in Figure 2 , do the following:
1. Connect a digital video source (for example, a digital video player 1) to the
SD/HD-SDI IN 1 connector.
2. Connect a digital video source (for example, a digital video player 2) to the
SD/HD-SDI IN 2 connector.
3. Connect the HDMI connector to an HDMI acceptor (for example, a plasma
display).
4. Using a small screwdriver, turn the SDI AUDIO GROUP SELECT rotary
switch to select an SDI stereo channel from 0 to 7.
5. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not illustrated in Figure 2 ).
!
