FC-321 - Technical Specifications
9
9
6
Technical Specifications
INPUTS:
2 SD/HD-SDI, 3G HD-SDI on a BNC connector
OUTPUT:
1 HDMI connector
MAX DATA RATE:
Up to 3Gbps
STANDARD COMPLIANCE:
HDMI
INDICATOR LEDS:
SD/HD, OUT, ON
POWER SOURCE:
5V DC, 480mA
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS
12cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0") W, D, H
WEIGHT:
0.3kg (0.7lbs)
ACCESSORIES:
Power supply
OPTIONS:
19” rack mount adapter
Specifications are subject to change without notice
